Resuscitation Unit with Fixed Baby Cradle

Resuscitation Unit with Fixed Baby Cradle

Resuscitation Unit with Fixed Baby Cradle & Drawers with Microprocessor based temperature controller with 4 modes Skin/Air/Manual / Pre warm Mode

Mechanical Specifications :

• Fixed height warmer with attached baby cradle mounted on 4 wheel
• Stainless steel baby tray with water proof, zipped cover mattress of density approx. 21-25 kg/m³
• Continuous head up/down facility
• X-Ray cassette holder
• Collapsible/lockable Side Supports made up of Unbreakable polycarbonate material
• Slots for sensor and ventilator tubing
• Side tray for placement of monitor
• Stainless steel infusion rod with facility to mount Syringe/infusion pump
• Lower shelf below baby tray to facilitate under surface phototherapy. Three drawer for storage.
• Integrated support for 10L Oxygen bottle.
• Oxygen regulator with pressure gauge, flow meter and humidifier bottle along with silicon tubing for delivery of oxygen from humidifier bottle to patient.
• Integrated electrical operated Slow Suction unit with Vacuum Regulator, Vacuum Gauge and autoclavable fluid jar.
• Silicone manual Resuscitator for Infant (250ml) along with face masks size 00 and 01.
• Laryngoscope  Penlight handle with straight blade size 0 and 1.
• Silicone Airways  size 000, 00, and 0

• Height : 74.5 (1890 mm), Width : 28.0 (710 mm), Length : 39.0 (990 mm)
• Bed to Floor Height : 37.5 (950 mm)
• Distance between baby bed and heater: 33 (840 mm)
• Mattress size: 30 (762 mm) x 20 (508 mm)
• Height of side panel above baby bed: 5.75 (145 mm)

• Microprocessor based temperature controller with Pre-warm, Manual and Skin Servo modes
• LED Display of Skin Temp., Air Temp., Set Temp. (Resolution 0.1°C) & Heater Power %.
• LCD to display modes of operation, Alarm messages, Skin Temperature in °F and Timer.
• Thermistor based sensor with Accuracy of +/- 0.2°C (Temp. Calibration not require)
• Modes of Operation: Skin Servo, Air, Manual and Pre-Warm
• Keypad lock facility
• Skin mode: Temperature range: 34 to 38°C , Resolution : 0.1°C
• Air mode: Temperature range: Room temp. to 39°C , Resolution : 0.1°C
• Manual mode: Adjustable Heater Power 0 to 100% (with an increment of 5%), Time duration : 15 mins
• Pre-warm mode: To pre-warm the cradle before baby is placed on the bed. (No alarm will be activated during Pre warm mode) Adjustable Heater Power 0 to 25% (with an increment of 5%), Time duration : 30 mins
• Overhead heater box : Swivelling, Consists of Ceramic heater (650 Watts) placed in parabolic reflector with a safety grill & Halogen observation light (12 V/50 W) for observing the baby
• Operating Voltage: 220-240 VAC, 50 Hz
• Power: 800 W (Max.)
• Alarm: Audio alarm with 10 minute mute facility & Visual alarms with message on LCD
• Power Fail Alarm: Audio with LED indicator
